| Rated Voltage/Current | Wire Gauge | Material | Number of Pins |
| 300V/12A | 26-14AWG |
Plastic: PA66 Pin (1): H2 Brass, Copper-Tin Plated Screw: C1018 Steel, Blue-White Zinc Plated Cage (1): C3604 Copper, Nickel plated Cage (2): Iron, Blue-White Zinc Plated |
2-24P ( Please send a request for the specific number of pins.) |
